Giant Trance X 29 2

Overview

Chunky rock gardens, roots and technical climbs. This hard-charging trail bike adapts to the terrain, giving you confidence and control on all types of singletrack.

Tech Specs

Bottom Bracket

SRAM DUB, press fit

Brake Levers

Shimano Deore BL-MT401

Brakes

Tektro HD M745,RT-66 rotors [F]203mm, [R]180mm

Cassette

SRAM SX, 11×50

Chain

SRAM SX Eagle

Colors

Metallic Black / Black, Amber Glow / Black

Crankset

SRAM SX, 30t S:165mm, M:170mm, L:170mm, XL:170mm

Extras

tubeless prepared, 2.5″ max tire size, 34t max chainring size

Fork

RockShox 35 Gold RL, 150mm, 44mm offset, 15×110 Maxle Stealth, custom tuned for Giant

Frame

ALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle

Front Derailleur

N/A

Grips

Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm

Handlebar

Giant Contact TR35, 780x35mm, 20mm rise

Hubs

alloy, sealed bearing

Pedals

N/A

Rear Derailleur

SRAM SX Eagle

Rims

Giant AM 29, alloy

Saddle

Giant Romero

Seatpost

Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mm

Shifters

SRAM SX Eagle, 1×12

Shock

Fox Float DPS Performance, 185/55, custom tuned for Giant

Sizes

S, M, L, XL

Spokes

Sapim

Stem

Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm

Tires

[F] Maxxis Minion DHF 29×2.5 WT, EXO, TR [R] Maxxis Dissector 29×2.4 WT, 60 TPI, 3C Max Terra, EXO, TR

Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Specifications

Bottom BracketSRAM DUB, press fitBrake LeversShimano Deore BL-MT401BrakesTektro HD M745,RT-66 rotors [F]203mm, [R]180mmCassetteSRAM SX, 11x50ChainSRAM SX EagleColorsMetallic Black / Black, Amber Glow / BlackCranksetSRAM SX, 30t S:165mm, M:170mm, L:170mm, XL:170mmExtrastubeless prepared, 2.5″ max tire size, 34t max chainring sizeForkRockShox 35 Gold RL, 150mm, 44mm offset, 15×110 Maxle Stealth, custom tuned for GiantFrameALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axleFront DerailleurN/AGripsGiant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mmHandlebarGiant Contact TR35, 780x35mm, 20mm riseHubsalloy, sealed bearingPedalsN/ARear DerailleurSRAM SX EagleRimsGiant AM 29, alloySaddleGiant RomeroSeatpostGiant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mmShiftersSRAM SX Eagle, 1x12ShockFox Float DPS Performance, 185/55, custom tuned for GiantSizesS, M, L, XLSpokesSapimStemGiant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mmTires[F] Maxxis Minion DHF 29×2.5 WT, EXO, TR [R] Maxxis Dissector 29×2.4 WT, 60 TPI, 3C Max Terra, EXO, TRWeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
