Overview
Chunky rock gardens, roots and technical climbs. This hard-charging trail bike adapts to the terrain, giving you confidence and control on all types of singletrack.
Tech Specs
Bottom Bracket
SRAM DUB, press fit
Brake Levers
Shimano Deore BL-MT401
Brakes
Tektro HD M745,RT-66 rotors [F]203mm, [R]180mm
Cassette
SRAM SX, 11×50
Chain
SRAM SX Eagle
Colors
Metallic Black / Black, Amber Glow / Black
Crankset
SRAM SX, 30t S:165mm, M:170mm, L:170mm, XL:170mm
Extras
tubeless prepared, 2.5″ max tire size, 34t max chainring size
Fork
RockShox 35 Gold RL, 150mm, 44mm offset, 15×110 Maxle Stealth, custom tuned for Giant
Frame
ALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle
Front Derailleur
N/A
Grips
Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
Handlebar
Giant Contact TR35, 780x35mm, 20mm rise
Hubs
alloy, sealed bearing
Pedals
N/A
Rear Derailleur
SRAM SX Eagle
Rims
Giant AM 29, alloy
Saddle
Giant Romero
Seatpost
Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mm
Shifters
SRAM SX Eagle, 1×12
Shock
Fox Float DPS Performance, 185/55, custom tuned for Giant
Sizes
S, M, L, XL
Spokes
Sapim
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
Tires
[F] Maxxis Minion DHF 29×2.5 WT, EXO, TR [R] Maxxis Dissector 29×2.4 WT, 60 TPI, 3C Max Terra, EXO, TR
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
Specifications
Bottom BracketSRAM DUB, press fitBrake LeversShimano Deore BL-MT401BrakesTektro HD M745,RT-66 rotors [F]203mm, [R]180mmCassetteSRAM SX, 11x50ChainSRAM SX EagleColorsMetallic Black / Black, Amber Glow / BlackCranksetSRAM SX, 30t S:165mm, M:170mm, L:170mm, XL:170mmExtrastubeless prepared, 2.5″ max tire size, 34t max chainring sizeForkRockShox 35 Gold RL, 150mm, 44mm offset, 15×110 Maxle Stealth, custom tuned for GiantFrameALUXX SL-Grade Aluminum front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axleFront DerailleurN/AGripsGiant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mmHandlebarGiant Contact TR35, 780x35mm, 20mm riseHubsalloy, sealed bearingPedalsN/ARear DerailleurSRAM SX EagleRimsGiant AM 29, alloySaddleGiant RomeroSeatpostGiant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mmShiftersSRAM SX Eagle, 1x12ShockFox Float DPS Performance, 185/55, custom tuned for GiantSizesS, M, L, XLSpokesSapimStemGiant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mmTires[F] Maxxis Minion DHF 29×2.5 WT, EXO, TR [R] Maxxis Dissector 29×2.4 WT, 60 TPI, 3C Max Terra, EXO, TRWeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
