Giant Talon 29 4

Overview

Push the pace on climbs, let loose on the descents. This aluminum hardtail gives you a feel for the trail with balanced, confident handling and a plush suspension fork.

Tech Specs

Bottom Bracket

cartridge

Brake Levers

RS360A, mechanical

Brakes

TKB-172, mechanical [F]160mm, [R]160mm rotors

Cassette

microSHIFT CS-H083, 12-46

Chain

KMC 8.3

Colors

Metallic Black, Metal

Crankset

ProWheel A10XPP, 30t (27.5) or 32t (29) XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)

Extras

2.4″ max tire size

Fork

SR Suntour XCE, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29)

Frame

ALUXX-Grade Aluminum, disc

Front Derailleur

N/A

Grips

Giant Sole-O

Handlebar

Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)

Hubs

alloy, sealed bearing

Pedals

MTB caged

Rear Derailleur

microSHIFT RD-M619

Rims

Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width

Saddle

Giant custom

Seatpost

Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)

Shifters

microSHIFT SL-M718, 1×8

Shock

N/A

Sizes

27.5: XS,S,M,L, 29: S,M,L,XL,XXL

Spokes

stainless, 14g

Stem

Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)

Tires

Kenda Booster 27.5 or 29×2.2″, wire bead

Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Specifications
