Overview
Steep climbs, technical descents, longer days on the trail. With a smooth suspension setup and a seamless boost of pedaling support, this E-bike gives you the power and technology to ride the trails you dream about.
Tech Specs
Battery
EnergyPak Smart 625Wh
Bottom Bracket
–
Brake Levers
Shimano MT401
Brakes
Shimano MT420, 4-piston, hydraulic disc, 203mm
Carrier
–
Cassette
Shimano CS-M6100-12, 10-51T, 12-speed
Chain
KMC e.12 Sport, e-bike optimized
Colors
Color A: Sapphire, Color B: Grenadine
Controller
RideControl Dash, full color LCD screen
Crankset
Forged Alloy minimal Q-factor, 36T Steel Direct Mount ring (S:160, M/L:165, XL:170)
Display
RideControl Dash, full color LCD screen
Fork
RockShox Recon Silver RL, 130mm travel, Lockout, 110x15mm Boost, Maxle Stealth, e-MTB optimized
Frame
ALUXX Aluminum, 120mm FlexPoint suspension system, 141mm Boost QR, Integrated KS18 Kickstand Mount
Grips
Giant Tactal single lock-on
Handlebar
Giant Connect TR Riser 31.8x780mm
Hubs
Shimano MT410 Boost / MT401, Center-Lock, [F] 110×15 [R] 141mm QR Micro-Spline Drive Body
Lighting
–
Motor
SyncDrive Sport, 70Nm, powered by Yamaha
Pedals
Aluminum Platform
Rear Derailleur
Shimano Deore, 12-speed
Rims
Giant AM 29″, Tubeless ready, 30mm inner width
Saddle
Giant Sport
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:100/M:125/L:150/XL:170)
Shifters
Shimano Deore, 12-speed
Shock
RockShox Monarch RT, High Volume, 184x44mm, custom tuned
Sizes
S, M, L, XL
Spokes
Stainless Steel
Stem
Giant Contact
Tires
Maxxis Rekon 29×2.4″ foldable, 60tpi, EXO, Tubeless Ready
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
Specifications
BatteryEnergyPak Smart 625WhBottom Bracket-Brake LeversShimano MT401BrakesShimano MT420, 4-piston, hydraulic disc, 203mmCarrier-CassetteShimano CS-M6100-12, 10-51T, 12-speedChainKMC e.12 Sport, e-bike optimizedColorsColor A: Sapphire, Color B: GrenadineControllerRideControl Dash, full color LCD screenCranksetForged Alloy minimal Q-factor, 36T Steel Direct Mount ring (S:160, M/L:165, XL:170)DisplayRideControl Dash, full color LCD screenForkRockShox Recon Silver RL, 130mm travel, Lockout, 110x15mm Boost, Maxle Stealth, e-MTB optimizedFrameALUXX Aluminum, 120mm FlexPoint suspension system, 141mm Boost QR, Integrated KS18 Kickstand MountGripsGiant Tactal single lock-onHandlebarGiant Connect TR Riser 31.8x780mmHubsShimano MT410 Boost / MT401, Center-Lock, [F] 110×15 [R] 141mm QR Micro-Spline Drive BodyLighting-MotorSyncDrive Sport, 70Nm, powered by YamahaPedalsAluminum PlatformRear DerailleurShimano Deore, 12-speedRimsGiant AM 29″, Tubeless ready, 30mm inner widthSaddleGiant SportSeatpostGiant Contact Switch, dropper, 30,9mm (S:100/M:125/L:150/XL:170)ShiftersShimano Deore, 12-speedShockRockShox Monarch RT, High Volume, 184x44mm, custom tunedSpokesStainless SteelStemGiant ContactTiresMaxxis Rekon 29×2.4″ foldable, 60tpi, EXO, Tubeless ReadyWeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
